74404024100
FIXED IND 10UH 470MA 435MOHM SMD
part Number：
74404024100
Alternative Model：
7440402
manufacturer：
Würth Elektronik Midcom
category：
Inductors, Coils, Chokes >
Fixed Inductors >
describe：
FIXED IND 10UH 470MA 435MOHM SMD
RoHS：
YES
74404024100 specifications
Mounting Type：
Surface Mount
Operating Temperature：
-40°C ~ 125°C
Shielding：
Shielded
Type：
Drum Core, Wirewound
Material - Core：
Ferrite
Tolerance：
±20%
Ratings：
AEC-Q200
Package / Case：
Nonstandard
Inductance：
10 µH
Size / Dimension：
0.098" L x 0.079" W (2.50mm x 2.00mm)
Inductance Frequency - Test：
1 MHz
Height - Seated (Max)：
0.047" (1.20mm)
Current Rating (Amps)：
470 mA
Frequency - Self Resonant：
30MHz
Current - Saturation (Isat)：
850mA
Supplier Device Package：
2520
DC Resistance (DCR)：
435mOhm
