IRF6621TR1
MOSFET N-CH 30V 12A DIRECTFET
part Number：
IRF6621TR1
Alternative Model：
manufacturer：
IR (Infineon Technologies)
category：
Discrete Semiconductor Products >
Transistors >
FETs, MOSFETs >
Single FETs, MOSFETs >
describe：
MOSFET N-CH 30V 12A DIRECTFET
RoHS：
NO
IRF6621TR1 specifications
Mounting Type：
Surface Mount
Operating Temperature：
-40°C ~ 150°C (TJ)
FET Type：
N-Channel
Technology：
MOSFET (Metal Oxide)
Drive Voltage (Max Rds On, Min Rds On)：
4.5V, 10V
Vgs (Max)：
±20V
Drain to Source Voltage (Vdss)：
30 V
Vgs(th) (Max) @ Id：
2.25V @ 250µA
Input Capacitance (Ciss) (Max) @ Vds：
1460 pF @ 15 V
Supplier Device Package：
DIRECTFET™ SQ
Package / Case：
DirectFET™ Isometric SQ
Power Dissipation (Max)：
2.2W (Ta), 42W (Tc)
Current - Continuous Drain (Id) @ 25°C：
12A (Ta), 55A (Tc)
Rds On (Max) @ Id, Vgs：
9.1mOhm @ 12A, 10V
Gate Charge (Qg) (Max) @ Vgs：
17.5 nC @ 4.5 V
